Description：
The series axial flow pump is a horizontal radial split, single-stage cantilever support structure; Reasonable structure, good anti cavitation performance, high reliability, widely used in high flow and low head situations, with medium solid content below 35%; The bearings are lubricated with thin oil; The shaft seal is a mechanical seal.
Get a Quote for Industrial Pumps Today
Send us your requirements (flow rate, head, medium, temperature), and our engineers will provide a professional solution within 12 hours.
Click to open WhatsApp Web or scan the QR code.
Contact our engineers directly via WhatsApp
| Part name | Material configuration | Part name | Material configuration |
| pump body | FPA/Carbon Fiber, Rubber, Graphite+304 | axle | Dual phase steel |
| impeller | silicon carbide | Machine seal | Pressureless sintered silicon carbide (SSIC) |
| short circuit | Silicon carbide+304 | Bearing body | HT200 |
| shaft sleeve | Non metallic+duplex steel | bearing | Imported bearings |
The parts in contact with the medium are all non-metallic materials
Cantilever rotor, adopting a front door structure, with a simple structure and easy maintenance, without the need to disassemble the pump body and pipelines.
The pump body is supported in the middle, and the rotor is well aligned.
Mechanical seals are used to ensure that the pump is leak free, safe, and reliable.
Transmission methods such as direct connection, belt drive, and reducer drive can be used
